This product is a new type of online residual chlorine water quality sensor independently developed by ERUN Group. It features high stability and high precision, and can accurately measure the residual chlorine value and temperature value in the solution.It is widely used for continuous real-time monitoring of residual chlorine in drinking water, wastewater, boiler water, aquaculture, biological and pharmaceutical industries.
Measuring Range | 0.00~20.00mg/L |
Measuring Accuracy | ±2%FS |
Temperature Measuring Range | 0.0~60.0℃ |
Temperature Sensor | NTC22K |
Response Time | 90%＜90S |
Medium Flow Rate | 15~30L/h |
Pressure Range | 0~1bar |
Housing Material | PC、Stainless steel |
Cable Length | Standard 5m |
Process Connection | M28*1.5 |
Electrical Connection | Pin type or BNC interface |
Installation Method | Flow-through type (flow cell) |
Output | 4~20mA three-wire system |
Data Communication | RS485 |
Power Supply | DC9~30V |
IP Rating | IP68 |
